Raspberry Pi 3 Model A+
The Raspberry Pi 3 Model A+ combines the powerful 64-bit quad-core processor of the Pi 3 B+ with the compact form factor of the Model A+. Featuring dual-band wireless LAN and Bluetooth 4.2, it's ideal for embedded and IoT projects where space and power efficiency matter.
With modular wireless compliance certification, the 3A+ simplifies integration into commercial products by reducing wireless compliance testing requirements – improving both cost and time to market.
Key Features
- 64-Bit Quad-Core CPU – BCM2837B0 Cortex-A53 at 1.4GHz
- Dual-Band Wi-Fi – 2.4GHz and 5GHz 802.11 b/g/n/ac
- Bluetooth 4.2/BLE – Built-in wireless connectivity
- Compact Form Factor – Same footprint as Pi 1 Model A+
- 40-Pin GPIO – Full HAT compatibility
- HDMI Output – Full-size HDMI for displays
- Camera & Display Ports – CSI and DSI connectors
Specifications
- SoC: Broadcom BCM2837B0
- CPU: Cortex-A53 64-bit quad-core @ 1.4GHz
- RAM: 512MB LPDDR2
- Wireless: 2.4/5GHz 802.11 b/g/n/ac, Bluetooth 4.2/BLE
- USB: 1× USB 2.0 port
- Video: Full-size HDMI, DSI display port
- Camera: CSI camera port
- Audio: 4-pole stereo output and composite video
- Storage: MicroSD slot
- GPIO: 40-pin header
- Power: 5V/2.5A via Micro USB or GPIO
- Operating Temperature: 0-50°C
Multimedia
- H.264/MPEG-4 decode (1080p30)
- H.264 encode (1080p30)
- OpenGL ES 1.1, 2.0 graphics
Ideal For
- Embedded and IoT projects
- Wireless applications
- Space-constrained installations
- Commercial product integration
Resources
